To meet the diverse needs of industrial scenarios, light suspended cleanroom cranes offer a wide range of specifications, covering different load capacities, spans, lifting heights, and control methods. With their superior cleanliness, flexible layout adaptability, and stable operation, suspended cleanroom cranes are widely used in high cleanliness environments such as semiconductors, biopharmaceuticals, precision electronics, and the food industry, providing an ideal solution for efficient, contamination-free material handling.

Advantages of Suspension Clean Room Cranes

1. Low-friction bearings, enclosed transmission, and optional oil-free lubrication.

2. Suitable for cleanrooms with limited clearance.

3. Can be mounted on existing steel structures, cleanroom roofs, or rails, with low retrofit costs.

4. Supports fiber rope/cleanroom chain hoists as lifting devices.

5. Smooth surfaces and removable covers facilitate cleaning.

When selecting a lightweight suspended cleanroom crane, pay close attention to the following parameters:

Cleanroom Class: Determine your environmental requirements (e.g., ISO Class 5/7/8) to decide the crane's cleanliness class.

Lifting Capacity: Typically ranges from 50kg to 2000kg; select based on the heaviest load.

Span and Lifting Height: The length of the track and the lifting range of the hoist are determined based on the factory structure and process flow.

Drive Method:

• Manual: Low cost, suitable for light-load, low-frequency applications.

• Pneumatic: Explosion-proof, no risk of electric sparks, but requires a clean compressed air source.

• Electric: Precise control, powerful, but dust protection for the motor is necessary.

Control Method: Wireless remote control, wired control, or integrated into a central control system.

Material: 304 or 304L stainless steel, aluminum alloy, special coated carbon steel.

Industry Application Scenarios

• Pharmaceutical and aseptic filling line loading and unloading;

• Semiconductor equipment and wafer cassette handling;

• Cleanroom loading and unloading in food production lines;

• Medical device assembly and equipment maintenance.
